MIZAR 1/10 Scale 4WD Off-road Electric RC Truck 2.4G Brushed High Speed RTR #RH1071
Width: 340mm
Height: 175mm
Wheelbase: 290mm
Tyre: ø 124.13 x 67mm
Gear Ratio: 11.3(H)/21.2(L)
It features new rubber tires and exquisite body design, alloy Front/Rear Susp. arm Holder, hydraulic shock absorbers as well as alum. upper plate, making the car more stable and drop resistant.
Equipped with 2.4GHz Proportional Radio System, playing a Brushless Smash, you are the most beautiful guys on the street.
Overview
After a year of research and repeated testing, our new baby has finally been born. It comes with love and will be welcomed by the market. It has a perfect appearance, stable structure, and a design with metal gears for high and low speeds, allowing RC enthusiasts to freely control. It can race at high speeds, climb at low speeds, and can reach angles of up to 60 degrees. The design of the wheelie bar helps it fly better and farther. Mizar is in your hands, Future is hold.
The steering rod is linked with the suspension to ensure precise handling.
The rear suspension adopts hydraulic shock absorbers, which can be adjusted in height to change damping and response speed, adapting to different road conditions.
- All-metal internal diff gears
- Switchable two speed gearbox
- Adjustable body post
- Hydraulic shock absorbers
- Front High Impact Bumper,can fit Led lights
- High Grip Nice and widened tires with a size of 124 x 67mm
- 1x1/10 MIZAR Brushed RTR
- 1x Transmitter and receiver sets
- 1x Wall charger
- 1x instruction manual
4xAAA Battery for the transmitter
features
Product specifications
|
Product Length |
18.11" ( 460mm) |
Speed Control |
40A |
|
Product Weight |
9.04 Ib (4.1KG) |
Spur gear |
60T |
|
Product Width |
13.39" (340 MM) |
Suspension |
Independent |
|
Radio |
2.4G |
Top speed |
35+ |
|
Scale |
1:10 |
Vehicle Size |
Standard |
|
Servo |
3KG + 6KG |
Vehicle Type |
Two speed Truck |
|
Shock Type |
Oil-filled, coilover spring |
wheelbase |
11.42" (290mm) |
|
Ball bearing |
Metal bushing |
Chassis |
Plastic |
|
Battery |
7.4V 4500 Li-ion |
Completion Level |
Ready to run |
|
body |
Pre-painted Polyvinyl Chloride |
Connector Type |
Tamiya plug |
|
Distance of remote control |
100-150M |
Drive Type |
Forward, brake, Reverse |
|
Charger |
USB charger |
Motor Size |
550 brushed |
|
Pinion gear |
30T |
Power Type |
Electric |
|
Product Height |
6.89" ( 175mm) |
Drive train |
4WD |
|
Operator Skill Level |
Beginner |
Play time |
10-15 minutes/cycle |
Product details
The front frame adopts a new bumper, which takes into account both protection and modification. Thickened susp arm supports the front suspension system and steering service. The steering rod is linked with the suspension to ensure precise handling.
The rear suspension adopts hydraulic shock absorbers, which can be adjusted in height to change damping and response speed, adapting to different road conditions.
Adjustable body post can be used to adjust the height/width and position of the car body to adapt to different body types. By adjusting the ground clearance of the car body, it can adapt to different road surfaces to ensure balance and stability during driving.
The dual speed vehicle is equipped with metal gears, which have corrosion resistance and deformation resistance to maintain long-term stable operation of the transmission system. Realize high and low speed gear switching through metal gear sets to enhance scene adaptability.
Wheelie,as a standard configuration, plays a great role this time. It suppresses the sinking of the rear of the car during high-speed driving, maintains balance, and works with a high torque motor to achieve rollover. It provides a temporary support point to prevent overturning during low-speed steep slope climbing.
The widened tires with a size of 124 x 67mm make the car more stable and domineering during driving. The unique pattern design increases the friction between the tire and the ground, and the multi-level structural characteristics enhance the durability and wear resistance of the tire, extending its service life.
