590 brush motor - Power supply for your RC car!
High torque and reliable performance; The no-load speed is 16,690 RPM, with explosive power and speed, providing more rapid straight-line acceleration.
It is easy to install, runs smoothly and is compatible with most ESCs.
Perfect for 1/8 & 1/10 scale Electric RC cars
Specifications:
-Diameter (mm): 36
-Length (mm): 72
-Shaft Dia. (mm): 3.17
-Weight (g): 270
-Votage: 7.2V DC
AT No Load
1) Speed = 16690 RPM
2) Current = 1.6 AMP
AT Stall Extrapolation
1) Torque= 3490 G.CM
2) Current=88 AMP
AT Maximum Efficienct
Efficiency = 67.9 %
Speed=14796 RPM
Torque =408 G.CM
Current = 12.5 AMP
Output = 62.1 Watts
1 x 590 Brushed Motor with 150mm wiring
-VRX RH817 Cobra EBD brushed
-VRX RH819 Blast 2.0 Brushed
