This brushless ESC is specifically designed for the high speed remote control cars and drifting cars, waterproof Powerful with 5.8V3A BEC T Plug for RC Car Boat, used high-quality MOSFETs and low-impedance circuitry reduce heat by 30%, achieving 95% efficiency for sustained performance, compatible with sensorless brushless motor, strong resistant current capability, excellent heat dissipation, easier programmed and compatible with pocket-sized program card.
SPECIFICATIONS
Model Number: H0072
Cont. Current/Burst Current: 45A/250A
Motor Type: For 2S Lipo or 6 Cells NiMh:
1. On-road: 3656-size or small motor with the KV < 5600
2. Off-road: Buggy/monster: 3660-size or small motor with the KV <3800
For 3S Lipo or 9 Cells NiMh:
1. On-road : 3660-size or small motor with the KV < 3800
2. Off-road: Buggy/monster: 3660-size or small motor with the KV < 2600
Suitable Car: 1:10 car
Resistance: 0.0015Ω
Battery: 2~3 cells Lipo /4~9 cells NiMh
BEC Output: 5.9V / 3A
Dimensions/Weight: 48.5 x 36.5 x 34mm, 76g
Water-proof and dust-proof for all -weather races
Specially designed for RC Car with excellent start-up
Acceleration and linearity features
Compatible with sensorless brushless motor
Mulitple protection features, low voltage cut-off protection
For lithium or nickel battery, over-heat protection/Throttle signal loss protection
1 x 45A ESC with deans plug
1 x User Manual
VRX RH1013 Sword MT Brushless
VRX RH1017 Spirit EBL Brushless
VRX RH1028 XBL EBL Brushless
VRX RH1066 Smash MT Brushless
VRX RH1068 Spirit EBL Brushless
VRX RH1070 Merak MT Brushless
VRX RH1045 Octane Brushless
VRX RH1045SC Blast 2.0 Brushless
VRX RH2016 BLITZ Brushless
VRX RH2012 Bullet Brushless
